JWEI LST03II-0912-RM – automatic sheet-fed digital cutter

JWEI LST03II-0912-RM is designed for print shops and packaging producers cutting varied contours without a dedicated cutting die. The system automates sheet feeding, cutting and collection; CCD registration helps align the cutting contour with print. Depending on tooling, operations include through cutting, kiss cutting, creasing and V-grooving. The manufacturer lists cardboard, grey board, E/F-flute corrugated board, self-adhesives, PVC and PP sheets, KT foam board and magnetic stickers. The thickness limit of up to 10 mm depends on material and tool. Listed tool options are not automatically included as standard equipment. Listed maximum speed is 1,500 mm/s and repeat accuracy is ±0.1 mm. The technical table and brochure state 15–45 seconds per SRA3 sheet and 70 seconds per B2 sheet depending on contour. These are indicative production figures; the manufacturer's introduction gives different times. Ethernet connectivity and PLT, DXF, XML and CF2 formats support cutting-file transfer. The model page describes a JWPS library with over 1,000 box designs, size adjustment, 3D preview and QR-based file selection. Software licences and availability depend on the selected configuration. The manufacturer also describes proximity detection with a stop function. Dimensions are 2,598 × 1,970 × 1,148 mm; the brochure lists 720 kg. Supply is 220 V ±10%, 50 Hz. The model page lists 5.5 kW and the brochure 4.49 kVA. These are different quantities; electrical installation requirements depend on the selected configuration.
